E-FB

Fluorescent Emergency Lighting

Encore E-FB

Overview

Fluorescent emergency ballasts that operate most fluorescent lamps, with or without an AC ballast, to provide emergency lighting. Operates one or two lamps in emergency mode from a long life, high temperature nickel cadmium battery for a minimum of 90 minutes. Works on switched and unswitched circuits and is compatible with instant, rapid, energy saving and electronic dimming ballasts. Suitable for inside, top or remote installation.

E-FB

Fluorescent Emergency Lighting

Encore E-FB
Encore E-FB

Overview

Fluorescent emergency ballasts that operate most fluorescent lamps, with or without an AC ballast, to provide emergency lighting. Operates one or two lamps in emergency mode from a long life, high temperature nickel cadmium battery for a minimum of 90 minutes. Works on switched and unswitched circuits and is compatible with instant, rapid, energy saving and electronic dimming ballasts. Suitable for inside, top or remote installation.

Specifications

Mounting Type

Inside, Top or Remote

Housing Spec

Painted steel case (except slim-line)

Power

2.5-8.0W

Battery Spec

NiCad

Compliance

UL damp location | NEC | NFPA 101

Phase

None

Features

Standard Features

Operates 1 or 2 lamps | High temperature NiCad battery | 90 minute emergency lighting | Dual 120/277V input | Switched or unswitched circuits | Test switch and AC On light | Time delay standard | UL damp location 0C to 50C

Available Options

Self-testing and self-diagnostics, select models (E) | Cold weather, select models (CW) | Low profile housing, some models (LP)

E-FB

Contact us to get a quote about this product

Features

Steel

Housing

1 or 2 Lamps

Faces

NiCad

Battery

120/277 VAC

Voltage
